Full Automatic KN95 4-6ply Face Mask Making Machine with Nose Bridge Inside Limited Discount In Stock
N95 Mask Production Line
Main Feature:
1. PLC program control, high stability, low failure rate;
2. The whole machine adopts aluminum alloy structure, beautiful, firm and rustless
3. Automatic adjustment system and tension detection system to reduce the defective rate
4. Automatic built-in nose bar, greatly reduce the production time.
5. Using ultrasonic system, stable performance, easy to operate.
Specification:
1. SIZE:7550*1200*2200
2. WEIGHT:3000KG
3. Production Capacity: ≥60pcs/min
4. Applicable size of raw material: ≤300
5. Machine power supply voltage:220V/50HZ(Transformer can be added according to customer's requirement)
6. Compressed air pressure requirements:0.6-0.8Mpa
7. control mode:PLC( Mitsubishi )
8. Power:7.5Kw
9. Operator:1 person
10. Provide machine operation and maintenance video
MACHINE CONFIGURATION
1. Welding hot forming equipment 1 SET (SIZE:1550*1200*1550)
2. Folding, blanking, cutting equipment 1 SET(SIZE:1950*950*1320)
3. Feeding equipment(SIZE:4050*900*2200)
4. Automatic rectifying system:4-6 PC(AS REQUIRED)
5. Tension detection system:4-6 PC(AS REQUIRED)
6. Die: 1 set of rolling die, cutter die and blank holder die
Advantage:
1. Fully automatic N95 production line
2. High stability, low failure rate, industrialized in appearance, sturdy without rust.
3. Computer PLC programming control, servo drive, high degree of automation.
4. Automatic tension control of raw materials to ensure the balance of raw material
5. Photoelectric detection of raw materials to avoid errors and reduce waste
6. Automatic Deviation Rectifier
7. We have automatic tensioning device to save the raw materials
MACHINE DETAILS
